Drilling Polymer In Kolkata
It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.
Projects
Let’s see our projects
Our Products
Our Products
- BT Drilling polymer
- Sodium hydroxide liquid
- caustic soda
- Sodium based Bentonite Powder
- BT concrete Pump
- Pipe line lubricant
- Artificial Grass
artesian construction
Physical Properties Of Polymer
Appearance : Powder-White free flow solid granules.
- Density : 1.00-1.01
- PH (0.1% solution) : 7.0 -8.0
- Solubility : Completely soluble
- Marsh Funnel Viscosity (0.1% solution) : Above 90 sec.
Function
Suitable for all soil types. The viscosity stabilizes the excavation in the Geo construction industry
Applications
Initially mix at a minimum rate of 0.8 kg/m3 of fresh water in mix tank. On smaller projects or highly mobile projects such as power lines may be applied at the point of excavation.
artesian construction
For the best performance of the product the following procedures to be followed
- EFFECTIVE SLURRY PRODUCTION: Adequate supply of water of good quality should be available for slurry making and water shall always be available to take care of scheduled operations and unknown contingencies. A tank for storage of water shall be used to ensure sufficient and undisturbed slurry mixing. The pH of water should be adjusted to 11 before adding BT Polymer. For bringing the water pH to the requirement add Sodium Hydroxide in a concentration of 48%@1 ltr per m3 of water DeChlorination chemicals can be used to treat out chlorine if present in water because chlorine destroys all polymer molecules and decreases the viscosity if chlorine content is greater than 3ppm.
- POLLUTANTS : Slurries with polymer are sensitive to various impurities, which occur in ground water, soil, cement and make-up water. Petroleum hydrocarbons, calcium, acidity, alkalinity, chlorine and sodium chloride are some pollutants that will affect the polymer. The procurement of groundwater samples and the analysis of such samples for pH and pollutants/impurities should be a standard procedure.
- POLYMER MIXING IN TANK : BT Polymer, Polymer when mixed in tanks shall be added to water that is passed through tube or hopper, across a stationery panel or surface, stirred or agitated, in a manner which avoids the formation of lumps and results in a homogeneous mixture of polymer in water. The polymer slurry may be agitated until required viscosity is developed and particles of partially dissolved polymer for not settle in the bottom. The required viscosity is attained in 30 minutes, Agitation is normally done by blowpipes, motorized stirrers or other suitable and effective means. The mixing tank should be constantly in agitation. Initially add 0.8kg per m3 of BT Polymer to the pH treated water and maintain the slurry’s viscosity>55 seconds for best results. In Case of direct usage at the excavation the application depends upon the soil condition and water supply presenting concentrations of CaCO3. The specific gravity of the fresh mix will be 1 gr/cm3. The slurry’s parameter range from 1.01 to1.04gr/cm3.
DOSAGE
| Soil Type | Initial Dosage (kg/m3) | Marsh funnel viscosity (sec) | Refreshment Dosage(kg/m3) | Marsh funnel viscosity (sec) |
|---|---|---|---|---|
|
Clay |
0.9--1.2+ |
55--70 |
0.6--0.9 |
55--70 |
|
Medium Sand |
1.0--1.4+ |
60--110 |
0.7--1.0 |
60--110 |
|
Coarse Sand |
1.3--1.9+ |
70--140 |
0.75--1.2 |
70--140 |
|
Gravel |
1.4--2.0+ |
80--150 |
0.8--1.25 |
80--150 |
PARAMETERS
| Parameters | Fresh Mix | Reused Slurry | Prior to concrete pour |
|---|---|---|---|
|
Viscosity (s) |
>60 |
>60 |
60-77 |
|
Marsh funnel |
|
|
|
|
Density (kg/m3) |
1-1.04 |
- |
=1.05 |
|
pH |
11--12 |
11--12 |
8--12 |
artesian construction
ADDITIVES
BT Bond a counterpart product for BT Polymer is recommended to be used when problem arises. The main application is to focus the fluid loss control and helps in stabilization in all soil conditions. The fluid loss is controlled in cohesionless soil, open corals, cobbles, etc. which results in low over-break of concrete, polymer consumption and time required for drilling because of skin friction. The product is directly added at the borehole excavation and the dosage varies depending on the field condition.
ADVANTAGES
- Excellent effects when pH of suspension is neutral to alkaline.
- Polymer powder works very good with little dosage (0.025%-0.2% depending on the kind of suspension, concentration and pH).
- Granulated, hence easy to handle and excellent storage stability.
- Environment friendly.
- suitable for all types of soil.
- Easily soluble in fresh as well as salt water.
- No disposal issues.
Pricing Plan
PUMPING FROM BOREHOLES/DRILLING PIT
Pumping from a borehole is not recommended unless a casing has been placed into a stable stratum which prevents the flow of water from other strata in significant quantities into the boring.
artesian construction
Our Tools
- All type of drilling tools.
